SONOTEC - EtherNet/IP Gateway

SONOTEC – C3 software

Parameterization software for Non-Contact Flow Meters

Click to enlarge

Features

  • Data logging with auto-save function
  • Minimizing maintenance costs
  • Configure and calibrate sensors onsite for different applications
  • Control sensor performance and outputs

Specifications

Brand

SONOTEC

SONOTEC

Description

The C³ Software is a milestone in user-friendliness and smart sensor technology.

Description

For engineers who work on processes and development, the newly developed software hub allows a straightforward application of SONOFLOW and SEMIFLOW sensors.

Sensor Operations

  • Easy sensor identification
  • Connection of up to 12 sensors simultaneously
  • Flow monitoring and volume totalization in real-time
  • Data logging functionality with auto-saving
  • Huge plot area with auto-scaling and zoom functionality
  • A password-protected interface with a clean interface
  • Monitoring screen with full-screen mode, perfectly suited to laboratory applications and process control
  • Customer-specific factory default settings

Sensor Adjustments

  • Set a correction / offset factor to adjust the sensor for customer-specific fluids or applications
  • Onsite sensor calibration
  • Customizable/definable pre-settings for specific applications
  • Setting sensor outputs/inputs for complex automation processes such as RS-485 network integration
  • Easy sensor output selection for optimal system integration
  • Loading different .hex / .c3cvb files for different applications
  • Assigning sensor names for easy identification

Supported devices: SONOFLOW® CO.55, SEMIFLOW® CO.65, SEMIFLOW® CO.66 PI Ex1, SONOFLOW® IL.52, Portable USB Data Converter, Remote Display RD.10
