SONOTEC – Portable USB Data Converter
Power Supply of SONOFLOW® and SEMIFLOW® Sensors
Features
- Easy power supply for flow sensors via a connected power bank
- Monitor real-time flow on flow meters with integrated display for small-scale lab applications
- Direct transfer of measurement data
- Convenient connection of flow sensors via USB and PC with C3 Software
Specifications
| Brand | SONOTEC |
|---|
Description
Convenient Power Supply & Data Communication.
Description
With the Portable USB Data Converter Type 023, non-contact flow meters from the SONOFLOW and SEMIFLOW series can be powered via standard USB power sockets. The sensor accessory has an 8-pin M12 connector and a standard USB plug implemented in a compact housing with integrated electronics.
Supported devices: SONOFLOW® CO.55, SEMIFLOW® CO.65, SONOFLOW® IL.52, C³ Software, Remote Display RD.10
Technical information
| Dimensions (L x W x H) | 50 x 25 x 15.5 mm |
| Materials | Housing: ABS; cable bend relief: PVC |
| Operating Voltage | 5 V |
| Current Consumption | max. 500 mA |
| Connectors | 8-pin M12 connector, USB 2.0 |
| Ambient Temperature | 0 … +60 °C |
| Protection Class | IP40 on USB side, IP65 at M12 connector |
| Accessories | Adapter cable (to Binder series 720) for SEMIFLOW sensors |
