SONOTEC – Remote Display RD.10

Remote Display for SONOFLOW® and SEMIFLOW® Sensors

Benefits

  • Easy and permanent flow monitoring
  • Adjusting sensors for different applications
  • Zero adjustment and volume reset
  • Compact PVC-C housing
  • Power supply: 24 VDC (12-30 V)

The Remote Display RD.10 can be easily connected to all SONOFLOW® and SEMIFLOW® sensors.

The sensor accessory not only guarantees real-time monitoring of the measured values. But also provides a clever option to operate the sensor without a PC or PLC. PVC-C housing meets protection class IP65 and is flexible for use in different environments.

Clear Visualization of Sensor Parameters :

The menu-driven display shows

  • Flow min. / Flow max. / Flow real
  • Total volume
  • Medial temperature
  • Status messages

 Easy sensor adjustment:

The Remote Display  ensures easy remote sensor adjustment

  • Zero calibration
  • Manual volume reset

Supported devices: SONOFLOW® CO.55, SEMIFLOW® CO.65, SONOFLOW® IL.52, C³ Software, Portable USB Data Converter, SEMIFLOW® CO.66 PI Ex1

Read more about Brand: SONOTEC

Dimensions (L x W x H)  68 x 44 x 27 mm
Materials  PVC-C housing
Measuring Screen  Flow, volume, temperature, min. flow, max. flow
Settings  Measurement units, sleep mode, display contrast, zero reset of sensor
Electrical Connection  8-pin M12 connector, DIN EN 61076-2-101:2012
Interfaces  0/4-20 mA, 0-20 kHz, PNP / NPN / Push-Pull, RS-485 (bus capable), digital input
Ambient / Media Temperature  0 to 50 °C, other temperatures available on request
Protection Class  PVC-C housing

    Certificates for this product is not ready yet and it is upon user request for Now!
