FLOWLINX – Sanitary Reducer

Connection between two different outer diameters of hose assemblies

Features

  • Manufactured in an ISO 8 Cleanroom
  • Sterilizable by Gamma Irradiation, ETO or Autoclave
  • Made of glass reinforced nylon
  • Compatible to ASME-BPE

Specifications

Brand

FLOWLINX

Description

FlowLinX Sanitary Reducers are designed for single use fluid transfer applications and are available in polypropylene material.

Description

As part of a complete system, FlowLinX’s Sanitary Reducers are compatible with other TC flanges that follow ASME-BPE specifications. The polypropylene material provides superior chemical compatibility with a wide range of chemicals and is ideal for use in pharmaceutical applications. The ASME-BPE-compliant flanges ensure that the product is designed and manufactured to meet the highest quality standards, providing a secure and leak-free connection.

Specification

  • Ups Class VI and animal component-free
  • Smooth Inner Surface for Superior Flow

Size : 3″ to 1.5″



REGULATORY INFORMATION :

  • Meets USP 88 Biological Reactivity Tests, Class VI, In Vivo., Resin is non-hemolytic in accordance with ISO 10993-4., Resin is non-cytotoxic in accordance with ISO 10993-5.
  • The material used to manufacture FlowLinX products is Phthalate-free.
  • Material is compliant with REACH/RoHS requirements.
  • Neither BPA nor Melamine is used in the formulation or manufacture of the resin product used to manufacture FlowLinX products.
  • The resin material used to manufacture FlowLinX products is non-cytotoxic in accordance with ISO 10993-5.

Technical information

MaterialsFormosa 5090R polypropylene resin
CertificatesMeets USP <88> Class VI, ISO 10993-4 and ISO 10993-5
ISO levelManufactured in an ISO 8 Cleanroom in accordance with ISO 14644 principles
Max. cumulative Gamma dose45kGy
Shelf life3 years, Non-Sterile/Non-Irradiated, 2 years Gamma irradiated
Autoclaving121°C for 20 minutes
