SONOTEC – Remote Display RD.10
Remote Display for SONOFLOW® and SEMIFLOW® Sensors
Benefits
- Easy and permanent flow monitoring
- Adjusting sensors for different applications
- Zero adjustment and volume reset
- Compact PVC-C housing
- Power supply: 24 VDC (12-30 V)
The Remote Display RD.10 can be easily connected to all SONOFLOW® and SEMIFLOW® sensors.
The sensor accessory not only guarantees real-time monitoring of the measured values. But also provides a clever option to operate the sensor without a PC or PLC. PVC-C housing meets protection class IP65 and is flexible for use in different environments.
Clear Visualization of Sensor Parameters :
The menu-driven display shows
- Flow min. / Flow max. / Flow real
- Total volume
- Medial temperature
- Status messages
Easy sensor adjustment:
The Remote Display ensures easy remote sensor adjustment
- Zero calibration
- Manual volume reset
Supported devices: SONOFLOW® CO.55, SEMIFLOW® CO.65, SONOFLOW® IL.52, C³ Software, Portable USB Data Converter, SEMIFLOW® CO.66 PI Ex1
Read more about Brand: SONOTEC
| Dimensions (L x W x H) | 68 x 44 x 27 mm |
| Materials | PVC-C housing |
| Measuring Screen | Flow, volume, temperature, min. flow, max. flow |
| Settings | Measurement units, sleep mode, display contrast, zero reset of sensor |
| Electrical Connection | 8-pin M12 connector, DIN EN 61076-2-101:2012 |
| Interfaces | 0/4-20 mA, 0-20 kHz, PNP / NPN / Push-Pull, RS-485 (bus capable), digital input |
| Ambient / Media Temperature | 0 to 50 °C, other temperatures available on request |
| Protection Class | PVC-C housing |
