SAINT-GOBAIN – C-flex Braided TPE Tubing-082
Reinforced with polyester yarn
RX: HGE
Features
- Up to five times higher burst pressures than non-braided materials.
- Compatible with overmolding technology for single-use systems
- Ultra-flexible, improved bend radius over non-reinforced tubing
- Compatible with autoclave and gamma irradiation
- Temperature range: -67°C to 135°C (-85°F to 275°F)
- Available in 15 and 25 foot lengths, custom lengths available upon request
Specifications
| Brand | SAINT-GOBAIN |
|---|
Description
C-Flex® Braided Tubing is braid-reinforced tubing designed to meet pharmaceutical and biopharmaceutical applications' demands for high-pressure fluid processing.
Description
C-Flex Braided tubing is manufactured with C-Flex 082 resin and provides better chemical resistance than other braided tubing products. C-Flex® Braided is produced using the C-Flex® 082 translucent ADCF (Animal Derived Component Free) material formulation. Reinforcement is provided by a polyester fiber that provides an increased pressure rating and improved bend radius.
Technical information
| Appearance | Translucent |
| Durometer, Shore A | 60 |
| Tensile Strength, psi (bar) | 1106 (76.3) |
| Elongation, at Break % | 874 |
| Tensile Modulus, @ 100%/300%, psi (bar) | 256/400 (17.7/27.6) |
| Compression Set Constant Defl., “B” (22hrs @ 70°C), % | 89 |
| Brittle Point, °C (°F) | -67 (-85) |
| Low Temperature Flexibility @ -65°C | Pass |
| Autoclavable | one time 30 minute cycle at 121°C |
| Gamma Irradiation | one time up to 40kGy |
