SAINT-GOBAIN – Tygon® 2475 I.B. High-Purity Pressure Tubing
To withstand higher pressures.
RX: HGI
Features
- No added plasticizer
- Tough braid reinforcement for elevated working pressures
- Same smooth inner fluid contact layer as Tygon® 2475
- Meets USP <88> Class VI
Specifications
| Brand | SAINT-GOBAIN |
|---|
Description
Tygon® 2475 I.B. high-pressure thermoplastic tubing is engineered with textile reinforcement to withstand higher pressures.
Description
Using the same smooth inner fluid contact layer as Tygon® 2475, Tygon 2475 I.B. may be successfully used for higher-pressure applications such as single-use UF/DF skids and chromatography skids. Tygon® 2475 I.B. is formulated without softening agents that may extract, reducing potential contamination of sensitive fluids in biopharmaceutical applications. The clear construction of Tygon® 2475 I.B. tubing makes it possible to visually inspect the fluid path and ensure consistency.
Technical information
| Gas(Ethylene Oxide) | Yes |
| Radiation | 45 kGy |
| Appearance | Clear |
| Durometer Hardness Shore A, 15 Sec | 72 |
| Maximum Recommended Operating Temperature, °F (°C) | 125 (52) |
| Brittleness by Impact Temperature, °F (°C) | -108 (-78) |
| Low Temperature Flexibility, °F (°C) (tubing) | -94 (-70) |
| Water Absorption, % 24 hrs. @ 23°C | <0.01 |
