ADCA – M3H 2-Weg Kogelkraan
Casting True Bore Kogelkraan
RX: KAB
Eigenschappen
- Losse flenzen maken het mogelijk om de afsluiter te installeren zonder uitlijnen van de laseindes.
- Na installatie van de afsluiter kan de flens 360º draaien voor de gewenste oriëntatie.
- Ontworpen voor gebruik met schone stoom
- Condensaat en andere vloeistoffen en gassen
- Vooral geschikt voor sanitaire en hygiënische toepassingen
- Geschikt voor gebruik met een manuele deurkrukken
Specificaties
| Merk | ADCA PURE |
|---|---|
| Connectie | |
| Cavity Filter | NO, YES |
| Sil and Greace Free | |
| Operation | Manual |
| Standard Connetion | |
| Afwerking | SF1, SF4 |
| Man. process | Casted |
| Materiaal | 316L (1.4404) |
Omschrijving
De M3H driedelige kogelkranen van ADCA zijn ontworpen voor gebruik met schone stoom, condensaat en andere gassen en vloeistoffen die worden gebruikt in aseptische processen.
Beschrijving
The product is mainly designed for the (bio) pharmaceutical industry.The valve is not designed as a control valve and should only be used as an isolating valve, fully open or fully closed.
Options:
- Antistatic device.
- Different sealing materials.
- Degreased for oxygen use.
- Tube weld with loose body flanges
- (360º rotation after installation).
- Cavity filler.
Technische informatie
| Maten | DIN: “DN10 to DN100″ True Bore ASME: IMP 1/2″ to 4” |
| Max. druk | 100 bar |
| Temperatuur berijk | -29 to 200°C |
| Connecties | DIN: Butt weld (voor orbitaal lassen, DIN), Tri-clamp (DIN) ASME: Butt weld (voor orbitaal lassen,, ASME BPE), Tri-clamp (ASME BPE) |
| Materiaal | -lichaam, connections: CF3M (316L) -Ball: 1.4404 (316L) -Seats: TFM 1600 |
| Afmaak | Inwendige operflakte SF1 |
| Operatie | manueel of actuator (electric or pneumatic) |
| Certificaten (standaard) | DIN: 3.1 materiaal, FDA, 2.2 surface finish, USP Class VI 121 ºC, PED, TSE/BSE ASME : 3.1 materiaal, FDA, USP Class VI 121 ºC, PED, TSE/BSE |
| Certificaten (optioneel) | DIN: 3.1 opervalkte afmaak ASME: 2.2 opervalkte afmaak, ATEX |
* Max. druk is afhankelijk van de temperatuur en doorlaat. Zie de druk/temperatuur tabel op de datasheets voor meer informatie.
Downloads
All Variations
| Artikelnummer | Size | Connectie | Cavity Filter | Sil and Greace Free | Operation | Standard Connetion | Afwerking | OEM | Hoeveelheid | Voeg toe aan winkelkar |
|---|---|---|---|---|---|---|---|---|---|---|
| Artikelnummer: KAB05CW3T5-2W- | Size: 1/2" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX15 | ||
| Artikelnummer: KAB05CC3T5-2W- | Size: 1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX15 | ||
| Artikelnummer: KAB05CW3TF-2W- | Size: 1/2" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB05CC3TF-2W- | Size: 1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB05WW3T5-1-- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MHXXXFXXTBX15 | ||
| Artikelnummer: KAB05CC3T5-2WO | Size: 1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXOCBX15 | ||
| Artikelnummer: KAB05WW3T5--W- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH9XFFXXTBX15 | ||
| Artikelnummer: KAB05CW3T5-2WO | Size: 1/2" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXOCTBX15 | ||
| Artikelnummer: KAB05WW3T5-OW- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB05WW3T5AAW- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB05WW3TF-2W- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB05WW3T5-2W- | Size: 1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX15 | ||
| Artikelnummer: KAB07CC3T5-2W- | Size: 3/4" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX20 | ||
| Artikelnummer: KAB07WW3TF-2W- | Size: 3/4" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB07WW3T5-1-- | Size: 3/4" | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MHXXXFXXTBX20 | ||
| Artikelnummer: KAB07CW3TF-2W- | Size: 3/4" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB07CC3TF-2W- | Size: 3/4" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB07WW3T5-2W- | Size: 3/4" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX20 | ||
| Artikelnummer: KAB07CW3T5-2W- | Size: 3/4" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX20 | ||
| Artikelnummer: KAB07WW3T5-2WO | Size: 3/4" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXOTBX20 | ||
| Artikelnummer: KAB07WW3T5--W- | Size: 3/4" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: MH9XFFEXTBX20 | ||
| Artikelnummer: KAB07WW3TFVAW- | Size: 3/4" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB10CC3TF-2W- | Size: 1" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB10WW3TFAAW- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB10CC3T5--W- | Size: 1" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH9XFFXXCBX25 | ||
| Artikelnummer: KAB10WW3TF-2W- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB10CC3T5AAW- | Size: 1" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB10CW3TF-2W- | Size: 1" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB10WW3TF--W- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: MH9XFFEXTBX25E-SF4 | ||
| Artikelnummer: KAB10WW3TFVAW- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF4 | OEM: -- | ||
| Artikelnummer: KAB10CW3T5-2W- | Size: 1" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX25 | ||
| Artikelnummer: KAB10CC3T5-2W- | Size: 1" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX25 | ||
| Artikelnummer: KAB10WW3T5--W- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH9XFFXXTBX25 | ||
| Artikelnummer: KAB10WW3T5-2W- | Size: 1" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX25 | ||
| Artikelnummer: KAB15CC3T5--W- | Size: 1.1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH9XFFXXCBX40 | ||
| Artikelnummer: KAB15CC3T5-2W- | Size: 1.1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX40 | ||
| Artikelnummer: KAB15WW3T5-2W- | Size: 1.1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX40 | ||
| Artikelnummer: KAB15CW3T5-2W- | Size: 1.1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX40 | ||
| Artikelnummer: KAB20CC3T5--W- | Size: 2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH9XFFXXCBX50 | ||
| Artikelnummer: KAB20CC3T5AAW- | Size: 2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB20CC3T5-2W- | Size: 2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX50 | ||
| Artikelnummer: KAB20WW3T5-2W- | Size: 2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX50 | ||
| Artikelnummer: KAB20CW3T5-2W- | Size: 2" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX50 | ||
| Artikelnummer: KAB25CC3T5-2W- | Size: 2.1/2" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX65 | ||
| Artikelnummer: KAB25CW3T5-2W- | Size: 2.1/2" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX65 | ||
| Artikelnummer: KAB25WW3T5-2W- | Size: 2.1/2" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX65 | ||
| Artikelnummer: KAB30CW3T5-2W- | Size: 3" | Connectie: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX80 | ||
| Artikelnummer: KAB30WW3T5-2W- | Size: 3" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX80 | ||
| Artikelnummer: KAB40CW3T5-2W- | Size: 4" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCTBX100 | ||
| Artikelnummer: KAB40WW3T5-2W- | Size: 4" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXTBX100 | ||
| Artikelnummer: KAB40CC3T5-2W- | Size: 4" | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH3XFFXXCBX100 | ||
| Artikelnummer: KAB60WW3F5-1W- | Size: 6" | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH1XFFXXTBX150 | ||
| Artikelnummer: KAB60WW3F5-1-- | Size: 6" | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Afwerking: SF1 | OEM: MH1XXFXXTBX150 | ||
| Artikelnummer: KAB05WW2T5-2W- | Size: DN15 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX15 | ||
| Artikelnummer: KAB05WW2T5-1-- | Size: DN15 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MHXXXFXXTDX15 | ||
| Artikelnummer: KAB05WW2T5AA-- | Size: DN15 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB05WW2T5---- | Size: DN15 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH9XXFXXTDX15 | ||
| Artikelnummer: KAB07WW2T5-2W- | Size: DN20 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX20 | ||
| Artikelnummer: KAB10CC2T5-2W- | Size: DN25 | Connectie: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXCDX25 | ||
| Artikelnummer: KAB10WW2T5-2W- | Size: DN25 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX25 | ||
| Artikelnummer: KAB10WW2T5-1-- | Size: DN25 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MHXXXFXXTDX25 | ||
| Artikelnummer: KAB10WW2T5AA-- | Size: DN25 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB12WW2T5-2W- | Size: DN32 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX32 | ||
| Artikelnummer: KAB15WW2T5-2W- | Size: DN40 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX40 | ||
| Artikelnummer: KAB15WW2T5AAW- | Size: DN40 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Afwerking: SF1 | OEM: -- | ||
| Artikelnummer: KAB15WW2T5-1-- | Size: DN40 | Connectie: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MHXXXFXXTDX40 | ||
| Artikelnummer: KAB20WW2T5-2W- | Size: DN50 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX50 | ||
| Artikelnummer: KAB25WW2F5-2W- | Size: DN65 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX65 | ||
| Artikelnummer: KAB30WW2F5-2W- | Size: DN80 | Connectie: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Afwerking: SF1 | OEM: MH3XFFXXTDX80 |
