ADCA – M3H 2-Way Ball Valve
Casting True Bore Ball valves
RX: KAB
Features
- Loose body flanges make it possible to install the valve without aligning welded end connections
- After installation, the valve can rotate 360º for the desired orientation
- Designed for use with clean steam
- Condensate and other liquids and gases
- Mainly suitable for sanitary and hygienic applications
- Suitable for use with manual lever handles
Specifications
| Brand | ADCA PURE |
|---|---|
| Connection | Clamp-Clamp, Clamp-Orbital, Orbital-Orbital |
| Cavity Filter | NO, YES |
| Sil and Greace Free | NO, YES |
| Operation | Manual, Bare shaft, Pneumatic NC |
| Standard Connetion | ASME Imperial, DIN |
| Finishing | SF1, SF4 |
| Man. process | Casted |
| Material | 316L (1.4404) |
Description
M3H three pieces body ball valves are open/close valves designed for use with clean steam, condensate, and other gases, and liquids applied in high purity and aseptic processes.
Description
The product is mainly designed for the (bio) pharmaceutical industry.The valve is not designed as a control valve and should only be used as an isolating valve, fully open or fully closed.
Options:
- Antistatic device.
- Different sealing materials.
- Degreased for oxygen use.
- Tube weld with loose body flanges
- (360º rotation after installation).
- Cavity filler.
Technical information
| Sizes | DIN: “DN10 to DN100″ True Bore ASME: IMP 1/2″ to 4” |
| Max. Pressure* | 100 bar |
| Temperature Range* | -29 to 200°C |
| Connections | DIN: Butt weld (extended for orbital welding, DIN), Tri-clamp (DIN) ASME: Butt weld (extended for orbital welding, ASME BPE), Tri-clamp (ASME BPE) |
| Material | -Body, connections: CF3M (316L) -Ball: 1.4404 (316L) -Seats: TFM 1600 |
| Finishing | Interior surfaces SF1 |
| Operation | manual or actuator (electric or pneumatic) |
| Certificates (standard) | DIN: 3.1 material, FDA, 2.2 surface finish, USP Class VI 121 ºC, PED, TSE/BSE ASME : 3.1 material, FDA, USP Class VI 121 ºC, PED, TSE/BSE |
| Certificates (optional) | DIN: 3.1 surface finish ASME: 2.2 surface finish, ATEX |
* Max. pressure is depending on the temperature and DN size. See the pressure/temperature rating on the datasheets for more information.
Downloads
All Variations
| RX CODE | Size | Connection | Cavity Filter | Sil and Greace Free | Operation | Standard Connetion | Finishing | OEM | Quantity | Add to Cart |
|---|---|---|---|---|---|---|---|---|---|---|
| RX CODE: KAB05CW3T5-2W- | Size: 1/2 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX15 | ||
| RX CODE: KAB05CC3T5-2W- | Size: 1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX15 | ||
| RX CODE: KAB05CW3TF-2W- | Size: 1/2 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB05CC3TF-2W- | Size: 1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB05WW3T5-1-- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MHXXXFXXTBX15 | ||
| RX CODE: KAB05CC3T5-2WO | Size: 1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXOCBX15 | ||
| RX CODE: KAB05WW3T5--W- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH9XFFXXTBX15 | ||
| RX CODE: KAB05CW3T5-2WO | Size: 1/2 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXOCTBX15 | ||
| RX CODE: KAB05WW3T5-OW- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB05WW3T5AAW- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB05WW3TF-2W- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB05WW3T5-2W- | Size: 1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX15 | ||
| RX CODE: KAB07CC3T5-2W- | Size: 3/4 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX20 | ||
| RX CODE: KAB07WW3TF-2W- | Size: 3/4 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB07WW3T5-1-- | Size: 3/4 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MHXXXFXXTBX20 | ||
| RX CODE: KAB07CW3TF-2W- | Size: 3/4 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB07CC3TF-2W- | Size: 3/4 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB07WW3T5-2W- | Size: 3/4 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX20 | ||
| RX CODE: KAB07CW3T5-2W- | Size: 3/4 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX20 | ||
| RX CODE: KAB07WW3T5-2WO | Size: 3/4 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: YES | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXOTBX20 | ||
| RX CODE: KAB07WW3T5--W- | Size: 3/4 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: MH9XFFEXTBX20 | ||
| RX CODE: KAB07WW3TFVAW- | Size: 3/4 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB10CC3TF-2W- | Size: 1 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB10WW3TFAAW- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB10CC3T5--W- | Size: 1 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH9XFFXXCBX25 | ||
| RX CODE: KAB10WW3TF-2W- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB10CC3T5AAW- | Size: 1 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB10CW3TF-2W- | Size: 1 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB10WW3TF--W- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: MH9XFFEXTBX25E-SF4 | ||
| RX CODE: KAB10WW3TFVAW- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF4 | OEM: -- | ||
| RX CODE: KAB10CW3T5-2W- | Size: 1 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX25 | ||
| RX CODE: KAB10CC3T5-2W- | Size: 1 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX25 | ||
| RX CODE: KAB10WW3T5--W- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH9XFFXXTBX25 | ||
| RX CODE: KAB10WW3T5-2W- | Size: 1 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX25 | ||
| RX CODE: KAB15CC3T5--W- | Size: 1.1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH9XFFXXCBX40 | ||
| RX CODE: KAB15CC3T5-2W- | Size: 1.1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX40 | ||
| RX CODE: KAB15WW3T5-2W- | Size: 1.1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX40 | ||
| RX CODE: KAB15CW3T5-2W- | Size: 1.1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX40 | ||
| RX CODE: KAB20CC3T5--W- | Size: 2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH9XFFXXCBX50 | ||
| RX CODE: KAB20CC3T5AAW- | Size: 2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB20CC3T5-2W- | Size: 2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX50 | ||
| RX CODE: KAB20WW3T5-2W- | Size: 2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX50 | ||
| RX CODE: KAB20CW3T5-2W- | Size: 2 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX50 | ||
| RX CODE: KAB25CC3T5-2W- | Size: 2.1/2 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX65 | ||
| RX CODE: KAB25CW3T5-2W- | Size: 2.1/2 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX65 | ||
| RX CODE: KAB25WW3T5-2W- | Size: 2.1/2 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX65 | ||
| RX CODE: KAB30CW3T5-2W- | Size: 3 | Connection: Clamp-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX80 | ||
| RX CODE: KAB30WW3T5-2W- | Size: 3 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX80 | ||
| RX CODE: KAB40CW3T5-2W- | Size: 4 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCTBX100 | ||
| RX CODE: KAB40WW3T5-2W- | Size: 4 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXTBX100 | ||
| RX CODE: KAB40CC3T5-2W- | Size: 4 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH3XFFXXCBX100 | ||
| RX CODE: KAB60WW3F5-1W- | Size: 6 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH1XFFXXTBX150 | ||
| RX CODE: KAB60WW3F5-1-- | Size: 6 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: ASME Imperial | Finishing: SF1 | OEM: MH1XXFXXTBX150 | ||
| RX CODE: KAB05WW2T5-2W- | Size: DN15 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX15 | ||
| RX CODE: KAB05WW2T5-1-- | Size: DN15 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MHXXXFXXTDX15 | ||
| RX CODE: KAB05WW2T5AA-- | Size: DN15 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB05WW2T5---- | Size: DN15 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Bare shaft | Standard Connetion: DIN | Finishing: SF1 | OEM: MH9XXFXXTDX15 | ||
| RX CODE: KAB07WW2T5-2W- | Size: DN20 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX20 | ||
| RX CODE: KAB10CC2T5-2W- | Size: DN25 | Connection: Clamp-Clamp | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXCDX25 | ||
| RX CODE: KAB10WW2T5-2W- | Size: DN25 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX25 | ||
| RX CODE: KAB10WW2T5-1-- | Size: DN25 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MHXXXFXXTDX25 | ||
| RX CODE: KAB10WW2T5AA-- | Size: DN25 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB12WW2T5-2W- | Size: DN32 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX32 | ||
| RX CODE: KAB15WW2T5-2W- | Size: DN40 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX40 | ||
| RX CODE: KAB15WW2T5AAW- | Size: DN40 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Pneumatic NC | Standard Connetion: DIN | Finishing: SF1 | OEM: -- | ||
| RX CODE: KAB15WW2T5-1-- | Size: DN40 | Connection: Orbital-Orbital | Cavity Filter: NO | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MHXXXFXXTDX40 | ||
| RX CODE: KAB20WW2T5-2W- | Size: DN50 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX50 | ||
| RX CODE: KAB25WW2F5-2W- | Size: DN65 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX65 | ||
| RX CODE: KAB30WW2F5-2W- | Size: DN80 | Connection: Orbital-Orbital | Cavity Filter: YES | Sil and Greace Free: NO | Operation: Manual | Standard Connetion: DIN | Finishing: SF1 | OEM: MH3XFFXXTDX80 |
